Comtech EF Data cdm-570a - Transmit (Tx) Parameter Commands and Queries

CDM-570A/570AL Satellite Modem with Optional Packet Processor
Revision 5
Serial-based Remote Product Management 8–10 MN-CDM570A
8.5.2 Transmit (Tx) Parameter Commands and Queries
Tx Priority System = ITF (Highest priority), FRM, TFT, TMD, TCR, TDR, and TSR (Lowest Priority), indicated by shading. Any change to a
higher priority parameter will override any of the lower priority parameters.
Parameter
Type
Command
(Instruction
Code and
Qualifier)
Arguments for
Command or
Response to
Query
Description of Arguments
Response to
Command
Query
(Instruction Code
and Qualifier)
Response to
Query
Unit
Interface Type
ITF=
1 byte,
value of 0 thru 8
Command or Query.
Sets or returns Terrestrial interface type in the form x, where:
0=EIA-422/EIA530 DCE
1=V.35 DCE
2=EIA-232 (sync).
3= G.703 T1 AMI (forces Rx and Tx data rates to 1544 kbps)
4= G.703 T1 B8ZS (forces Rx and Tx data rates to 1544 kbps)
5= G.703 E1 Unbal AMI (forces Rx and Tx rates to 2048 kbps)
6= G.703 E1 Unbal HDB3 (forces Rx and Tx rates to 2048 kbps)
7= G.703 E1 Bal AMI (forces Rx and Tx rates to 2048 kbps)
8= G.703 E1 Bal HDB3 (forces Rx and Tx rates to 2048 kbps)
9 = IP Interface
A = IP-ACM (valid only in CDM-570A Compatibility Mode (CMO=1))
B = VersaFEC-2 ACM (requires VFEC-2 option card)
Example: <0/ITF=2 (V.35)
Note: When ITF is set as G.703, Clock Extension Mode is automatically set as
0=None. Response=ITF+
ITF=
ITF?
ITF*
ITF#
ITF+
ITF?
ITF=x
(see Description
of Arguments)
Unit Framing
Mode
FRM=
1 byte,
value of 0 or 1
Command or Query.
Sets or returns unit operating mode in theform x, where:
0=Unframed
1= EDMAC Framing
2= EDMAC-2 Framing
Example: <0/FRM=1 (EDMAC Framing)
FRM=
FRM?
FRM*
FRM#
FRM+
FRM?
FRM=x
(see Description
of Arguments)
