CDM-570A/570AL Satellite Modem with Optional Packet Processor
Revision 5
Front Panel Operation 6–55 MN-CDM570A
6.3.3.7 MONITOR: CnC
Appendix G. DOUBLETALK CARRIER-IN-CARRIER OPTION
When you select CnC and the demod is not locked, the modem displays the following message:
CnC:
Demod Not Locked
When CnC is enabled and the demod is locked, the screen displays the CnC performance data.
This read-only display updates once every second:
PR=+01.1dB PSDR=+01.1dB
ΔF=-002.3kHz Dly=249.6ms
6.3.3.8 MONITOR: ODU (CDM/R-570AL L-Band Units ONLY)
See Chapter 10. CDM-570A/570AL ODU (TRANSCEIVER, BUC, LNB) M&C
OPERATIONS for complete details about this modem-specific menu branch.
Outdoor Unit Monitor:
BUC LNB (▲ ▼,ENTER)
For the CDM/R-570AL only: Use this menu branch to monitor a BUC or LNB, if connected. Use
the ▲▼arrow keys to select BUC or LNB. Press ENTER to continue or CLEAR to return to the
previous menu.
6.3.4 SELECT: TEST
TEST: Mode BERT
Use the
◄ ► arrow keys to select Mode or BERT. Press ENTER.
