CDM-570A/570AL Satellite Modem with Optional Packet Processor
Revision 5
Ethernet-based Remote Product Management 7–35 MN-CDM570A
7.4.3.3.3 Configuration | ARP
1. This page is available only to Admin users and when you install the optional
Packet Processor.
2. If you submit any changes to this page, you must also open the ‘Admin | Pap
Save’ page (see Sect. 7.4.3.2.8) and immediately click [Save PaP
Parameters].
ARP (Address Resolution Protocol) is a technique by which the HTTP Interface in Router Mode
on a given network answers the ARP queries for a network address that is not on this network,
but is reachable via the Packet Processor Interface.
Use this page to configure the modem’s ARP parameters.
Figure 7-19. Configuration | ARP Page
ARP Table (Edit)
This section displays the current Static and Dynamic ARP entries and, when more than one ARP
entry exists, allows you to directly edit the current Static ARP entries:
This is the internal table index that is automatically assigned and cannot be edited.
IP Address, in the format XXX.XXX.XXX.XXX.
MAC Address, in the format YY:YY:YY:YY:YY:YY.
This column identifies the ARP Type as Static or Dynamic. It cannot be edited.
Click [Submit Changes] to save.
