CDM-570A/570AL Satellite Modem with Optional Packet Processor

Revision 5

Installation and Startup 2–1 MN-CDM570A

Chapter 2. INSTALLATION AND

STARTUP

2.1 Unpack and Inspect the Shipment

Figure 2-1. Unpack and Inspect the Shipment

The CDM-570A/570AL Satellite Modem, its optional Installation and Operation Manual (otherwise

available online at http://www.comtechefdata.com), and its power cord were packaged and

shipped in a reusable cardboard carton containing protective foam spacing (Figure 2-1).

CAUTION – THIS EQUIPMENT CONTAINS PARTS AND ASSEMBLIES SENSITIVE

TO DAMAGE BY ELECTROSTATIC DISCHARGE (ESD). USE ESD

PRECAUTIONARY PROCEDURES WHEN HANDLING THE EQUIPMENT.
