Comtech EF Data cdm-570a - SELECT:) Config (Configuration) Menus

CDM-570A/570AL Satellite Modem with Optional Packet Processor
Revision 5
Front Panel Operation 6–8 MN-CDM570A
6.3.2 (SELECT:) Config (Configuration) Menus
CDM-570AL/CDMR-570AL:
CDM-570A:
CONFIG: Rem All Tx Rx CEx
Frame TI Ref Msk CnC ODU
CONFIG:Rem All Tx Rx CEx
Frame TI Ref Msk CnC ◄ ►
Use the ◄ ►arrow keys to select a submenu choice available from the SELECT: Config menu
branch. Press ENTER.
Submenu
Sect.
Function
Rem 6.3.2.1
(Remote Control) Used to define whether the modem is being controlled
locally, or remotely.
All 6.3.2.2
This submenu is highly recommended for new users, as it leads you through
the complete modem configuration process on a step-by-step basis.
Tx 6.3.2.3
(Transmit) Used to define, on a per-parameter basis, the Tx configuration of
the unit. These menu submenu branches would be used if you wished to
change, for example, just the Tx Frequency..
Rx 6.3.2.4
(Receive) Used to define, on a per-parameter basis, the Rx configuration of the
unit. These menu submenu branches would be used if you wished to change,
for example, just the Rx data rate.
CEx
6.3.2.5
(Clock Extension) Used to define the G.703 Clock Extension interface.
Frame 6.3.2.6
(Framing) Used to define operation in a transparent mode (no framing) or in a
framed mode. In the framed mode, an overhead of 5% or 1.6% is added to the
rate transmitted over the satellite so that M&C and AUPC information may be
passed to the distant end.
TI 6.3.2.7
(Data Traffic Interface) Used to define RS422, IP, RS232, V.35, G.703, or IP-
ACM data traffic interfaces.
IP, VersaFEC ACM (IP-ACM), and VersaFEC-2 ACM (V2-ACM) are
available only when the optional High-Performance Packet
Processor is installed.
Ref 6.3.2.8
(Reference) Used to define whether the modem should use its own internal
10MHz reference, or phase lock to an externally applied reference and, if so, at
what frequency.
Msk 6.3.2.9
(Alarm Mask) Used to mask certain alarms that may cause operational
problems.
CnC 6.3.2.10
Used to select DoubleTalk Carrier-in-Carrier (CnC) options.
Appendix G. DOUBLETALK CARRIER-IN-CARRIER (CNC)
ODU
(CDM-570AL,
summary only)
6.3.2.11
(Outdoor Unit) For the CDM/R-570AL only – Used to configure a BUC (Block
Up Converter) or LNB (Low-Noise Block Down Converter), if connected.
Chapter 10. CDM-570A/570AL ODU (TRANSCEIVER, BUC, LNB)
M&C OPERATIONS
