CDM-570A/570AL Satellite Modem with Optional Packet Processor
Revision 5
Front Panel Operation 6–38 MN-CDM570A
6.3.2.7 CONFIG: TI (Data Traffic Interface)
Data Intf: RS422 IP V.35
RS232 G703 IP-ACM V2-ACM
Use the
◄ ► arrow keys to select a parameter. Press ENTER.
6.3.2.7.1 (CONFIG: TI) RS422 or V.35 or RS232
RTS/CTS Operation: (▲ ▼)
RTS/CTS Loop, No Action
For RS422, V.35, or RS232, the modem displays this typical submenu. Use the ▲▼arrow keys to
select an option. Press ENTER.
Parameter
Description
Ignore RTS, Assert CTS
RTS is ignored and CTS is asserted unconditionally.
Loop, RTS Controls Tx
Out
RTS and CTS are looped, so that CTS echoes the state of RTS, and RTS
controls the ON/OFF state of the carrier (in other words, the modem will not
bring up its TX carrier until RTS is asserted).
RTS/CTS Loop, No
Action
RTS and CTS are looped, so that CTS echoes the state of RTS, but RTS
does not control the ON/OFF state of the carrier.
N/A - 1:N system in use
If the 1:N switch on the rear panel is active, then RTS/CTS are not supported;
the pins are assigned to redundancy functions.
6.3.2.7.2 (CONFIG: TI) IP
This selection is functional only when the optional Packet Processor is installed.
Select IP to toggle the optional Packet Processor operation. Once you select IP, the modem
returns you to the SELECT: Config menu branch.
6.3.2.7.3 (CONFIG: TI) G.703
G.703 is not available when in IP mode.
G.703 Type: T1
E1-Bal E1-Unbal(◄ ►,ENT)
Use the
◄ ► arrow keys to select T1, E1-Bal, or E1-Unbal. Press ENTER.
