CDM-570A/570AL Satellite Modem with Optional Packet Processor
Revision 5
ODU (Transceiver, BUC, LNB) Operation 10–48 MN-CDM570A
10.3.3 CDM/R-570AL BUC and LNB M&C via Serial Remote Control
Commands/Queries
Chapter 8. SERIAL-BASED REMOTE PRODUCT MANAGEMENT
The operands available through CDM/R-570AL Serial-based Remote Product Management are
identified in the following table – details on using these ODU-specific remote commands and
queries are explicitly defined in Chapter 8.
Operand
Description
RNE
Query only – the unit returns the oldest 5 Stored Events which have not yet been read over the
remote control.
OGC
Command or Query – ODU Global Configuration of CDM/R-570AL
FLT
Query only – Unit returns the current highest-priority fault and status codes for the unit (hardware),
Tx Traffic, Rx Traffic and ODU
