Comtech EF Data cdm-570a - Satellite Modem > Monitor > Stored Events

CDM-570A/570AL Satellite Modem with Optional Packet Processor
Revision 5
Optional Packet Processor - Serial/Telnet CLI Operation 9–57 MN-CDM570A
9.3.8.2.1 Satellite Modem > Monitor > Stored Events
Open the nested Stored Events page from the Monitor page.
Figure 9-41. Stored Events
Selection
Hot Key
Description
Number of Unviewed Stored
Events
[RO]
Displays the total number of unread stored events. As stored event
groups are displayed, the counter decrements accordingly.
Jump To First Stored Event J
Upon selection, sets the listings for Hot Key ‘V’ to the first event that
was stored subsequent to the latest buffer reset.
View Next 5 Stored Events V
Buffers the next group of five stored events into the events window.
Event information is presented as shown in Figure 9-41.
Clear All Stored Events
C
Erases all entries from the stored events logging buffer.
