CDM-570L/570AL Satellite Modem with Optional Packet Processor

Revision 5

Optional High Performance Packet Processor D–3 MN-CDM570A

D.1.1.3 High-Performance Packet Processor Field Upgrade Procedure

D.1.1.3.1 Overview

This section describes the field upgrade procedure you need to follow to retrofit your CDM-570A/570AL Satellite Modem with the optional

Packet Processor card. See Section D.1.1.2 in this appendix for the requirements and limitations of using the Packet Processor with the

CDM-570A/570AL.

D.1.1.3.2 Requirements for Field Upgrade

• CDM-570A/570AL Satellite Modem

• Medium Phillips screwdriver

• CEFD P/N KT-0020931 Packet Processor Upgrade Kit, containing:

CEFD Part Number

QTY

Description

PL-0021625

CDM-570A/570AL-Packet Processor Card

HW/SEM440X1/4PH

Screw, S.S., 4-40 x 1/4 LG, Pan Head Phillips
