CDM-570A/570AL Satellite Modem with Optional Packet Processor
Revision 5
Ethernet-based Remote Product Management 7–10 MN-CDM570A
7.4.1.4 Action Buttons
Action buttons are important in the CDM-570A HTTP Interface. Click an action
button to do one of these tasks:
• Reset changed parameters to remove unsaved changes.
• Permanently save changes.
• Refresh the page with current data.
If you edit a field, make sure to click the action button before you leave the
page. If you go to another page without first clicking the action button, your
7.4.1.5 Drop-down Lists
A drop-down list lets you choose from a list of selections. Left-click the drop-
down button to open the list. Then, left-click on an item to select that choice.
When an optional FAST feature is not available, its associated
drop-down list appears dimmed and is non-selectable.
7.4.1.6 Text or Data Entry
Text boxes let you type data into a field. An action button may
be associated with a single text box, or a group of text boxes.
For any text box, left-click anywhere inside the box, type the
desired information into that field, and be sure to press
[ENTER] when done.
Click the related action button to save the data.
If you edit any field, make sure to click the action button before you leave the
page. If you go to another page without first clicking the action button, your
7.4.2 CDM-570A HTTP Interface – Menu Tree
Figure 7-1 shows the HTTP Interface common to both the CDM-570A and CDM/R-570AL
modems. Beyond the top-level row of navigation tabs (shown in blue), available nested navigation
tabs (shown in green or yellow) afford more specific functionality.
