CDM-570A/570AL Satellite Modem with Optional Packet Processor
Revision 5
ODU (Transceiver, BUC, LNB) Operation 10–15 MN-CDM570A
(ODU SELECT ► INFO):Transmitter
Tx: ON 5845.0MHz 10.00dB
AMP:ON Unmuted Sl:0.0
This screen shows information on the CSAT transmitter status: Tx operating state (ON or
OFF); Tx Frequency; Tx Attenuation; Amplifier state (ON or OFF); Tx Mute state (Muted or
Unmuted); and Tx Slope adjustment.
(ODU SELECT ► INFO): Receiver
Rx: ON 3570.0MHz 10.00dB
Unmuted Sl:0.0
This screen shows information on the CSAT receiver status: Rx operating state (ON or OFF);
Rx Frequency; Rx Attenuation; Rx Mute state (Muted or Unmuted); and Rx Slope
adjustment.
(ODU SELECT ► INFO): LNA
LNA: On Window: 99%
Fault Logic: No-Summary
This screen shows the current state of the LNA functions: the LNA operating status (ON or
OFF); the Current Window; and Fault-Logic settings (Summary or No-Summary).
(ODU SELECT ► INFO): Misc
Cold Start: Off
Auto Fault Recovery: On
This screen shows the current state of the Cold Start and Auto Fault Recovery functions as
ON or OFF.
10.2.1.2.1.1.1.3 (ODU SELECT:) Monitor
ODU MONITOR: Tx Rx Misc
Pwr-Supp1 Pwr-Supp2 (◄ ►)
For access to real-time information displays on the ODU currently in operation, use the ◄ ►
arrow keys to select Tx, Rx, Misc, Pwr-Supp1, or Pwr-Supp2. Press ENTER when done.
The read-only screen shots that follow depict sample configurations – the actual
values and settings will vary and they are dependent on the ODU configuration
in use. Typical for all nested screens, press ENTER or CLEAR to return to the
ODU SELECT: Monitor menu.
(ODU SELECT ► ODU MONITOR:) Tx
TX: SynTune=04.8 Pwr=040
IFLO = 10.7 Temp = 27 oC
This screen shows the Tx Synthesizer and IFLO tuning voltages, the RF Output Power in
dBm and the Transmitter temperature.
