CDM-570A/570AL Satellite Modem with Optional Packet Processor
Revision 5
Serial-based Remote Product Management 8–39 MN-CDM570A
8.5.5 Bulk Configuration Commands and Queries
Parameter
Type
Command
(Instruction
Code and
Qualifier)
Arguments for
Command or
Response to
Query
Description of Arguments
Response to
Command
Query
(Instruction Code
and Qualifier)
Response to
Query
OGC Outdoor Unit
Global
Configuration
OGC=
50 Bytes
Command or Query – CDM/R-570AL only.
Sets or returns ODU Global Configuration of CDM/R-570AL in the form
aabcdexxxxhhhhiiiijjjjjkxxxxxxlmnnnooopppppqxxxxxx, where:
OGC=
OGC?
OGC*
OGC#
OGC?
OGC?n
OGC=aabcdfxxxhhh
hiiiijjjjjkxxxxxxlmnnn
ooopppppqxxxxxx
Where n=0 to 9
returns the OGC
portion of 1 of 10
stored configs
(see Description of
Arguments)
aa = BUC Address
b = BUC FSK comms enable
c = BUC Power Control
d = BUC 10MHz Frequency Reference enable
e = BUC Tx Output Enable
xxxx = expansion bytes
hhhh = BUC Low Alarm Limit
iiii = BUC High Alarm Limit
jjjjjk = BUC LO frequency, mix sign
xxxxxx = expansion bytes
l = LNB Power Control
m = LNB 10MHz Frequency Reference enable
nnn = LNB Low Alarm Limit
ooo = LNB High Alarm Limit
pppppq = LNB LO Frequency, mix sign
xxxxxx = expansion bytes
Any unavailable parameters will be filled with xxx.
same as BAD
same as BCE
same as BPC
same as BFR
same as BOE
same as BCL
same as BCH
same as BLO
same as LPC
same as LFR
same as LCL
same as LCH
same as LLO
Global
Configuration in
CDM-570A
Compatible Mode
(CMO=1)
MGC=
200 bytes, with
numerical entries,
fixed values, and
delimiters.
Command or Query.
Sets or returns Global Configuration of CDM570AL, in CDM-570A Compatible
Mode (CMO=1), in the form shown in Response to Query column, where:
a = Unit Interface Type same as ITF
b = T1 Line build-out same as LBO
c = Unit Framing mode same as FRM
dddd.dddd = Tx Frequency same as TFQ
e = Tx FEC Type same as TFT
f = Tx Modulation type same as TMD
g = Tx FEC Rate same as TCR
hhhhh.hhh = Tx Data Rate same as TDR
i = Tx Spectrum Inversion same as TSI
MGC=
MGC?
MGC*
MGC#
MGC?
MGC?n
MGC=abcdddd.ddd
defghhhhh.hhhijkk.k
lmnoppp.ppqrrstxxx
AAAA.AAAABCDE
EEEE.EEEFGHIIIJJ
.JKLMxxxxxxNOPP
PPQRRRRRRRRR
RRRSTUVxxxxxxm
MATrrrr.rrrssss.sss
abxcedfffgggGGGh
xxxxxxxxxxxxxxxxx
xxxxxxxxxxxxxxxxx
xxxxxxxxxxxxx
