CDM-570A/570AL Satellite Modem with Optional Packet Processor
Revision 5
Ethernet-based Remote Product Management 7–8 MN-CDM570A
7.4 CDM-570A HTTP (Web Server) Interface
A user-supplied Web browser allows the full M&C of the CDM-570A/570AL from its HTTP
Interface. This non-secure embedded Web application is designed for, and works best with,
Microsoft Internet Explorer Version 7.0 or higher.
7.4.1 Operational Features
7.4.1.1 User Login
Type the CDM-570A/570AL Ethernet Traffic IP Address (shown in this example as
http://192.168.1.11) into the Address area of the user PC Web browser:
The login window, similar to the example shown here, opens.
Enter the assigned User Name and Password. The CDM-
570A HTTP Interface default user names and passwords are
as follows:
• Admin comtech/comtech
• Read/Write opcenter/1234
• Read-only monitor/1234
HTTP Login User Access Levels are further defined as follows:
Full Access to all web
pages
Full Access for all other web pages
View Only Access for all other web pages
If login is attempted and remote control is set to either Local or Remote mode,
access is prohibited and the following error message displays in the browser
window:
To properly access the CDM-570A HTTP Interface, configure remote control
access for the unit to Ethernet mode. Click [Enable Ethernet Mode].
Alternately, from the CDM-570A/570AL front panel, use the ◄ ► and ▲ ▼ arrow keys to first
navigate to the remote control configuration menu, and then select Ethernet mode (press ENTER
when done):
SELECT: CONFIG ► Rem ► Ethernet
