CDM-570A/570AL Satellite Modem with Optional Packet Processor
Revision 5
Ethernet-based Remote Product Management 7–34 MN-CDM570A
Port Configuration (with optional Packet Processor INSTALLED)
• Port – This column identifies the active/available IP ports.
• Mode and Speed – Use the drop-down list to select the speed for the active port as
Auto, 10 Mbps Half Duplex, 100 Mbps Half Duplex, 10 Mbps Full duplex, or 100
Mbps Full Duplex.
Click [Submit Port Cnfg] to save.
• Actual Negotiated Port Speed – This column identifies the port’s current operational
speed and send/receive settings.
VLAN Brouter (with optional Packet Processor INSTALLED)
VLAN Brouter mode operation is special mode of operation where VLAN traffic is bridged and
non-VLAN traffic in routed using static route table information.
When Brouter mode is used in a hub-spoke network, the remote routers receives the whole
outbound traffic transmitted by the hub. Since VLAN traffic is transmitted to the remote routers
using a broadcast HDLC address, the receiver FPGA in the remote CDM-570A/570ALs will
forward all the traffic to the CPU. In addition to the hub receiving traffic the remote routers shall
also forward the return link (remote to hub) traffic.
• Typical for VLAN Brouter Mode, VLAN Brouter Tx Payload Compression, VLAN
Remote Mode, and VLAN Filtering – Use the drop-down lists to Enable or Disable
operation.
• VLAN Brouter Next Hop MAC Address – Enter the desired Next Hop IP Address for
toEth routes. Note that no Next Hop entry is needed for toSat routes.
• VLAN ID 1 through VLAN ID 10 – You may assign up to 10 VLAN ID addresses within
the range from 0001 to 4095.
Click [Submit Changes] to save.
Make sure to also click [Save PaP Parameters] on the ‘Admin | PaP Save’ page
before proceeding further .
