CDM-570A/570AL Satellite Modem with Optional Packet Processor
Revision 5
Front Panel Operation 6–12 MN-CDM570A
To edit the SNMP Trap Read or Write Community strings, use the ◄ ► arrow keys to
select a character to edit. Then, use the ▲▼arrow keys to edit that character. Note that
only the first 20 characters on the bottom line are available.
All printable ASCII characters are available with the exception of the backslash ‘/’
(ASCII code 92) and tilde ‘~’ (ASCII code 126).
Press ENTER once you compose the string – the modem removes all trailing spaces
from the string upon entry.
(CONFIG: Remote Control) Ethernet: SNMP Traps
Version
Trap Version:
SNMPv1 SNMPv2 (◄ ►,ENT)
Use the ◄ ► arrow keys to select the SNMP Trap Version as SNMPv1 or SNMPv2.
Press ENTER.
(CONFIG: Remote Control) Ethernet: SNMP Traps IP
Addr#1 or Addr#2
Trap IP #X: (◄ ►,▲ ▼)
000.000.000.000
Where ‘X’ indicates Trap IP #1 or Trap IP #2: To edit the Trap Destination IP Address,
use the
◄ ► arrow keys to select a digit, and then use the ▲▼arrow keys to change
that digit. Press ENTER.
If you define both Trap IP Addresses as 000.000.000.000, this
disables the Traps.
