CDM-570A/570AL Satellite Modem with Optional Packet Processor
Revision 5
Ethernet-based Remote Product Management 7–17 MN-CDM570A
System Account Access Information
• Read-only, Read/Write, Admin Names and Passwords – The factory defaults for these
user names and passwords are as follows:
Factory Default User Name / Password
Name and Password fields can be any
alphanumeric combination with a maximum
length of 10 characters.
• SMTP Server – Specify the mail server IP Address from where e-mail may be sent.
• SMTP Domain Name / Destination – The Administrator can assign the SMTP Domain
Name and Destination. This is required if the e-mail feature of the ‘Home | Support’ page
is to be used.
o For SMTP Domain Name, specify the domain of the e-mail server (usually found to
the right of the @ symbol in an e-mail address).
o For SMTP Domain Destination, specify the e-mail recipient name (usually found to
the left of the @ symbol in an e-mail address).
Host Access List
• IP (#) / Mask – Use the Host Access List to define which remote clients can connect
when the Access List is Enabled. Each entry allows access to a unique class of
machines. Enter an IP address and a subnet mask.
For example, if it is desired to grant access to a PC with an IP Address of 10.10.10.1,
and any PC on a subnet of 192.168.10.xxx, then the Access List would be defined as:
IP 1 / Mask: 10.10.10.1/32
IP 2 / Mask: 192.168.10.0/24
For IP 3 / Mask and IP 4 / Mask, make sure they are not 0.0.0.0/0. An entry with
0.0.0.0/0 simply means any machine is allowed access.
• Access List – Use the Access List to grant access via HTTP and SNMP to a well-
defined list of client machines. Use the drop-down list to select Enable or Disable. If
Disabled, then any client machine can connect via HTTP and SNMP.
Click [Submit Admin] to save.
