CDM-570A/570AL Satellite Modem with Optional Packet Processor
Revision 5
Serial-based Remote Product Management 8–13 MN-CDM570A
Parameter
Type
Command
(Instruction
Code and
Qualifier)
Arguments for
Command or
Response to
Query
Description of Arguments
Response to
Command
Query
(Instruction Code
and Qualifier)
Response to
Query
Tx FEC Code
Rate
(continued)
Y = VersaFEC-2 ModCod 3 – QPSK 0.586
Z = VersaFEC-2 ModCod 4 – QPSK 0.611
a = VersaFEC-2 ModCod 5 – QPSK 0.635
b = VersaFEC-2 ModCod 6 – QPSK 0.660
c = VersaFEC-2 ModCod 7 – QPSK 0.684
d = VersaFEC-2 ModCod 8 – QPSK 0.733
e = VersaFEC-2 ModCod 9 – 8-ARY 0.521
f = VersaFEC-2 ModCod 10 – 8-ARY 0.537
g = VersaFEC-2 ModCod 11 – 8-ARY 0.562
h = VersaFEC-2 ModCod 12 – 8-ARY 0.586
I = VersaFEC-2 ModCod 13 – 8-ARY 0 .611
j = VersaFEC-2 ModCod 14 – 8-ARY 0.635
k = VersaFEC-2 ModCod 15 – 8-ARY 0.660
l = VersaFEC-2 ModCod 16 – 8-ARY 0.684
m = VersaFEC-2 ModCod 17 – 8-ARY 0.708
n = VersaFEC-2 ModCod 18 – 8-ARY 0.733
o = VersaFEC-2 ModCod 19 – 16-ARY 0.586
p = VersaFEC-2 ModCod 20 – 16-ARY 0.611
q = VersaFEC-2 ModCod 21 – 16-ARY 0.635
r = VersaFEC-2 ModCod 22 – 16-ARY 0.660
s = VersaFEC-2 ModCod 23 – 16-ARY 0.684
t = VersaFEC-2 ModCod 24 – 16-ARY 0.708
u = VersaFEC-2 ModCod 25 – 16-ARY 0.733
v = VersaFEC-2 ModCod 26 – 16-ARY 0.757
w = VersaFEC-2 ModCod 27 – 16-ARY 0.782
x = VersaFEC-2 ModCod 28 – 32-ARY 0.660
y = VersaFEC-2 ModCod 29 – 32-ARY 0.684
z = VersaFEC-2 ModCod 30 – 32-ARY 0.708
“ = VersaFEC-2 ModCod 31 – 32-ARY 0.733
& = VersaFEC-2 ModCod 32 – 32-ARY 0.757
@ = VersaFEC-2 ModCod 33 – 32-ARY 0.782
[ = VersaFEC-2 ModCod 34 – 32-ARY 0.801
] = VersaFEC-2 ModCod 35 – 32-ARY 0.831
{ = VersaFEC-2 ModCod 36 – 32-ARY 0.855 (Long Block only)
} = VersaFEC-2 ModCod 37 – 32-ARY 0.879 (Long Block only)
Note: Selection availability depends on the active FEC and Modulation type.
Example: <0/TCR=4 (Rate 3/4)
