CDM-570A/570AL Satellite Modem with Optional Packet Processor
Revision 5
Serial-based Remote Product Management 8–37 MN-CDM570A
Parameter
Type
(Instruction
Code and
Qualifier)
Command or
Response to
Query
Description of Arguments
Response to
Command
Query
(Instruction Code
and Qualifier)
Response to
Query
Directs the CDM570AL to store the current modem configuration into the
Configuration Memory location 0 through 9.
Example: <0/CST=4 (stores the current configuration in location 4)
CST?
CST*
Forces a hard reset of the unit in 5 seconds.
FRB?
FRB*
thru 2
Demo Mode Enable/Disable in the form of x, where:
0 = Disabled
1 = Enabled
2 = Expired
Note: Changing value from 0 to 1, or 1 to 0, causes the modem to turn off
carrier output and reboot.
DMM?
DMM*
DMM#
(see Description of
Arguments)
0 or 1
Sets or returns Carrier ID On/Off State in the form x, where:
0=Off
CAI?
CAI *
(see Description of
Arguments)
Sets or returns the Carrier ID Latitude, in the form ddaaamm.mmbbbD, where:
dd=degrees Latitude,
aaa=fixed value “deg”.
mm.mm=decimal minutes of the Latitude.
Bbb=fixed value “min”.
D=direction (N (North) or S (South)).
EXAMPLE: <0/LAT=33deg59.99minN (Latitude is 33º59.99΄N)
LAT?
bbbD
(see Description of
Arguments)
Longitude
Sets or returns the Carrier ID Longitude, in the form dddaaamm.mmbbbD, where:
ddd=degrees Longitude,
aaa=fixed value “deg”.
mm.mm=decimal minutes of the Longitude.
bbb=fixed value “min”.
D=direction (E (East) or W (West)).
EXAMPLE: <0/LNG=111deg59.99minE (Longitude is 111º59.99΄E)
LNG?
mbbbD
(see Description of
Arguments)
Telephone Number
Sets or returns the Carrier ID Telephone Number (maximum length is 18
characters).
EXAMPLE: <0/PHN=18664723963
PHN?
(see Description of
Arguments)
