CDM-570A/570AL Satellite Modem with Optional Packet Processor
Revision 5
Serial-based Remote Product Management 8–46 MN-CDM570A
Parameter
Type
Command
(Instruction
Code and
Qualifier)
Arguments for
Command or
Response to
Query
Description of Arguments
Response to
Command
Query
(Instruction Code
and Qualifier)
Response to
Query
Equipment ID
in CDM-570
Compatible Mode
(CMO=0)
N/A
11 bytes
Query only.
Returns information concerning the equipment identification and the option field, in
CDM-570 Compatible Mode (CMO=0), in the form abbbcdefghi; where:
a = Turbo option:
0 = None,
1 = Turbo
bbb defines the modem model number:
570 = CDM-570A, 571 = CDM/R-570AL
c = Expansion slot:
0 = None
1 = Reed-Solomon codec installed
d = Data Rate Option:
0 = Base (512 kbps)
1 = up to 2048 kbps
2 = up to 5000 kbps
3 = up to 10239 kbps
e = Higher-order modulation:
0 = None
1 = 8-PSK/8-QAM
2 = 16QAM
3 = 8-PSK/8-QAM and 16QAM
f = Packet Processor:
0 = None
1 = IP Mod_v1
2 = IP Mod_v2
g = BUC option:
0 = None
1 = 100 Watt
2 = 150 Watt
h = G.703 Clock Extension:
0 = None
1 = Installed
i= G.703 Line Interface
0 = None
1 = Installed
N/A
EID?
EID= abbbcdefghi
(see Description of
Arguments)
570 is the CDM-
570A
571 is the CDM-
570A L-Band
