CDM-570A/570AL Satellite Modem with Optional Packet Processor
Revision 5
Optional Packet Processor - Serial/Telnet CLI Operation 9–28 MN-CDM570A
Assign or Edit a QoS Rule
When you select a rule to create or edit (Hot Key 1 through 8), the CLI prompts you to assign
parameters in this order:
Screen Prompt
Action
Specify Protocol for the rule
Specify your desired rule protocol:
1 for UDP (User Datagram Protocol)
2 for TCP (Transmission Control Protocol)
3 for ICMP (Internet Control Message Protocol)
4 for RTP (Real Time Protocol (includes all RTP – VOCE, VDEO, and RTPS))
5 for VOCE (Voice RTP)
6 for VDEO (Video RTP)
7 for RTPS (RTP Signaling)
8 for FTP (File Transfer Protocol only)
9 for HTTP (Hypertext Transfer Protocol)
10 for TELN (Telnet)
11 for SMPT (Simple Mail Transfer Protocol)
12 for SNMP (Network Management Protocol)
13 for SAP (Service Announcement Protocol)
14 for ORCL (Oracle application traffic)
15 for CTRX (Citrix application traffic)
16 for SQL (Structured Query Language)
17 for IP (Internet Protocol (all inclusive))
18 for N-IP (Non-Internet Protocol (all inclusive))
Specify priority for the rule
Where Priority 1 = Highest, and Priority 8 = Lowest:
1 for QoS Priority-1
2 for QoS Priority-2
3 for QoS Priority-3
4 for QoS Priority-4
5 for QoS Priority-5
6 for QoS Priority-6
7 for QoS Priority-7
8 for QoS Priority-8
Maximum bandwidth in kbps
<0-99999, enter = 99999>:
Type your Maximum Bandwidth, in kbps, from 0 to 99999. If you desire no such
parameter, press [Enter] – the bandwidth defaults to ‘99999’.
Source IP address
<enter = 0.0.0.0>:
Type your Source IP Address in the form XXX.XXX.XXX.XXX. If you desire no
Source IP Address, press [Enter] – the address displays as ‘***’.
Number of Source subnet bits
<0,8-32, enter = 0>:
Type your Source subnet bits value, from 8 to 32. If you desire no Source subnet.
type ‘0’ or press [Enter] – the subnet displays as ‘/*’.
Destination IP address
<enter = 0.0.0.0>:
Type your Destination IP Address in the form XXX.XXX.XXX.XXX. If you desire no
Destination IP Address, press [Enter] – the address displays as ‘***’.
Number of Destination subnet
bits <0,8-32, enter = 0>:
Type your Destination subnet bits value, from 8 to 32. If you desire no Destination
subnet. type ‘0’ or press [Enter] – the subnet displays as ‘/*’.
Specify TCP/UDP source port
[MIN] (1-65535) <Enter: ***>
Set the minimum TCP/UDP source port in your range, from 1 to 65535.
If you desire no minimum TCP/UDP source port, press [Enter] – the port displays as
‘***’.
Specify TCP/UDP source port
[MAX] (1-65535) <Enter: ***>
This prompt will not display if you do not select a MIN TCP/UDP source port.
Set the maximum TCP/UDP source port in your range, from 1 to 65535.
Specify TCP/UDP destination
port [MIN] (1-65535) <Enter:
***>
Set the minimum TCP/UDP destination port in your range, from 1 to 65535. If you
desire no minimum TCP/UDP destination port, press [Enter] – the port displays as
‘***’.
