CDM-570A/570AL Satellite Modem with Optional Packet Processor
Revision 5
Optional Packet Processor - Serial/Telnet CLI Operation 9–39 MN-CDM570A
Selection
Hot Key
Description
VLAN Brouter Remote
Mode Enable
R
Toggle as [Enabled] or [Disabled].
In this mode, IP traffic received from the WAN interface will not be
forwarded back to the WAN interface, even though the route table
matches.
Each remote modem must have Remote Mode enabled,
indicating this is a distant-end modem.
VLAN Filtering
F
Toggle bridging for all "Brouted" VLAN destination packets and routing of
non-VLAN traffic as [Enabled] or [Disabled].
VLAN ID 1 through 10
0001
thru
4094
Assign a numeric VLAN ID in the range from 0001 to 4094.
The VLAN ID is a 12-bit field in the Ethernet packet that
contains the IEEE-802.1Q tag.
• VLAN ID 0001 is reserved and used for normal switch
operation.
• A maximum of 10 VLAN ID matches are supported.
Unused VLAN ID match fields must be set to values that
DO NOT match any network VLAN IDs.
