CDM-570L/570AL Satellite Modem with Optional Packet Processor

Revision 5

Optional High Performance Packet Processor D–44 MN-CDM570A

Remote Site ‘B’ – CDM-IP Remote Modem ‘B’

IP Address: 10.10.1.4

VLAN Match Filter – Enabled

Remote Site ‘C’ – CDM-IP Remote Modem ‘C’

IP Address: 10.10.1.5

VLAN Match Filter – Enabled

Note that, in this configuration, the management of the CDM-IP modems can either be included in

VLAN 1200 or left outside of all VLANs, since all remotes process all non-VLAN traffic.

Chapter 9. OPTIONAL PACKET PROCESSOR – SERIAL/TELNET CLI OPERATION
