Front Panel Operation Revision 4
CDM-760 Advanced High-Speed Trunking Modem MN-CDM760
6–39
6.2.2.4.4.3.1 (CONFIG: INTF) (PIICX=ASI)  TxMode
TxMode:ASI-Norm Frame:TS-188 ReStamp:Off
DataRate:100000.000 kbps
Use the   arrow keys to select a parameter. Press ENTER.
(CONFIG: INTF) (PIICX=ASI)  TxMode  TxMode
Use the  arrow keys to select ASI-Off, ASI-Norm, or ASI-Adv. Press ENTER.
(CONFIG: INTF) (PIICX=ASI)  TxMode  Frame
Use the  arrow keys to select None, TS-188, or TS-204. Press ENTER.
(CONFIG: INTF) (PIICX=ASI)  TxMode  ReStamp
Use the  arrow keys to select Off or On. Press ENTER.
(CONFIG: INTF) (PIICX=ASI)  TxMode  DataRate
Use the  arrow keys to select a Data Rate from 1000.000 to 216000.000 kbps. Press ENTER.
6.2.2.4.4.3.2 (CONFIG: INTF) (PIICX=ASI)  RxMode
RxMode:ASI-Norm Frame:TS-188 Type:Stream
DataRate:100000.000 kbps
Use the   arrow keys to select a parameter. Press ENTER.
(CONFIG: INTF) (PIICX=ASI)  RxMode  RxMode
Use the  arrow keys to select ASI-Off or ASI-Norm. Press ENTER.
(CONFIG: INTF) (PIICX=ASI)  RxMode  Frame
Use the  arrow keys to select None, TS-188, or TS-204. Press ENTER.
(CONFIG: INTF) (PIICX=ASI)  RxMode  Type
Use the  arrow keys to select Burst or Stream. Press ENTER.
(CONFIG: INTF) (PIICX=ASI)  RxMode  DataRate
Use the  arrow keys to select a Data Rate from 1000.000 to 216000.000 kbps. Press
ENTER.
