7.4.4.3.8 Configuration | Test
Figure 7-24. Configuration | Test Page
See Chapter 6. FRONT PANEL OPERATION for detailed information about the Bit
Error Rate Test (BERT) configuration and operation parameter controls provided on
this page:
Web Page Section
Chapter 6 Section Reference
Unit
6.2.4.1 (TEST:) Mode
BERT Config
6.2.4.2 (TEST:) BERT  Off/On,  Patt
BERT Monitor
6.2.4.2 (TEST:) BERT  ErrIns,  Restart
Unit
Use the drop-down list to select the desired Test Mode.
Click [Submit] to save.
BERT Config
Use the drop-down lists to turn the Tx BERT On or Off, and to set the desired test pattern (when
On).
Click [Submit] to save.
BERT Monitor
Click [Insert Error] or [Restart BERT] to alter the ongoing BERT.
