Appendix C Revision 4
CDM-760 Advanced High-Speed Trunking Modem MN-CDM760
C–9
C.2.4 DVB ASI (Asynchronous Serial Interface) PIIC Module (CEFD P/N
PL-0022015)
Figure C-10. G.703 E3/T3/STS-1 PIIC Module
Name
Connector Type
Description
Direction (I/O)
ASI-IN BNC Data In I
ASI-OUT BNC Data Out O
Figure C-7. DVB ASI (Asynchronous Serial Interface) PIIC Module Panel
Connectors
