Ethernet Interface Operation Revision 4
CDM-760 Advanced High-Speed Trunking Modem MN-CDM760
7–27
7.4.4.3.3 Configuration | ARP (Address Resolution Protocol)
This page is accessible only to Admin users when the optional High-Speed Packet
Processor card is installed and enabled. See Sect. 7.4.3.1 for information about
using conditional access pages.
Use this page to configure the modem’s P0 | MGMT port ARP (Address Resolution Protocol)
parameters.
ARP is a way of associating a MAC address with an IP address for all devices that are active on a
broadcast domain. The modem can associate these addresses dynamically (by listening to ARP
responses) or statically (by hard-coding the IP/MAC Address association).
Figure 7-14. Configuration | ARP Page
ARP Table (Edit)
The ARP Table contains all known associations – it displays all current Static and Dynamic ARP
entries, and allows you to directly edit the current Static ARP entries when more than one ARP
entry exists. Note the following:
This is the read-only internal table index number. It is automatically assigned.
IP Address, in the format XXX.XXX.XXX.XXX.
MAC Address, in the format YY:YY:YY:YY:YY:YY.
This read-only column displays the entry type as Static or Dynamic.
