Comtech EF Data CDM-760 - Carrier ID

Serial Interface Operation Revision 3
CDM-760 Advanced High-Speed Trunking Modem MN-CDM760
8–46
8.5.14 Carrier ID
Parameter Type
Controller-to-Target
Instruction Code and
Qualifier
Arguments for
Command or
Query
Description of Arguments
(Note that all arguments are ASCII numeric codes from 48 to 57)
Target-to-Controller
(see Description of Arguments)
Command Query
Response to
Command
Response to
Query
Carrier ID Mute
MUT=
MUT?
1 byte, value of 0
or 1
Command or Query.
Sets or returns mute mode in the form x, where:
0=Carrier ID is On.
1=Carrier ID is Off (Muted).
EXAMPLE: <0/MUT=0 (Turns Carrier ID On)
MUT=
MUT?
MUT*
MUT#
MUT=x
Carrier ID Latitude
LAT=
LAT?
8 bytes
Command or Query.
Sets or returns Latitude in the form mmss.ssh, where:
mm=Latitude in Minutes
ss.ss=Latitude in decimal Seconds
h=Hemisphere (N or S).
EXAMPLE: <0/LAT=3325.43N
LAT=
LAT?
LAT*
LAT#
LAT=mmss.ssh
Carrier ID
Longitude
LNG=
LNG?
9 bytes
Command or Query.
Sets or returns Longitude in the form mmmss.ssh, where:
mmm=Longitude in Minutes
ss.ss=Longitude in decimal Seconds
h=Hemisphere (E or W).
EXAMPLE: <0/LAT=11158.28W
LNG=
LNG?
LNG*
LNG#
LNG=mmmss.s
sh
Carrier ID Phone
Number
PHN=
PHN?
Variable 1 to 18
bytes
Command or Query.
Sets or returns a variable length string denoting Phone Number
String can consist of any of the characters “+0123456789x “ (not including “)
‘+’ and ‘ ‘ (Space) are ignored/deleted when sending and ‘x’ denotes extension.
EXAMPLE: <0/PHN=+18664723963 x123
PHN=
PHN?
PHN *
PHN #
PHN=x
Carrier ID Custom
Message
MSG
MSG?
Variable 1 to 24
bytes
Command or Query.
Sets or returns a variable length string with a Custom Message
String can consist of any printable character.
EXAMPLE: <0/MSG=Comtech EFData
MSG=
MSG?
MSG*
MSG #
MSG=x
