Front Panel Operation Revision 4
CDM-760 Advanced High-Speed Trunking Modem MN-CDM760
6–5
6.2 CDM-760 Front Panel Menus
The primary and nested menus available from the CDM-760 front panel are described in this
section.
The actual choices displayed in the submenus depend on which FAST options are
enabled. Where a FAST option affects a menu, this is explained in the sections that
follow in this chapter.
Table 6-2. CDM-760 Front Panel Menus
Menu Branch Display Description
Opening Screen
Comtech CDM-760 Advanced High-Speed
Trunking Modem ver X.X.X
Press ENTER to access the SELECT:
(main) menu or, from any other screen,
press CLEAR repeatedly to return to this
screen. This top-level (splash) screen
identifies the modem and its running
Select (main)
SELECT: Configuration Monitor Test
Store/Ld 0Utility ODU FAST
Use to access all monitor and control
submenus.
Configuration
CONFIG: NetSpec Tx Rx Intf CnC Comp
DPD Remote IP Mask Ref MEO
Select to fully configure the modem.
Monitor
Monitor: Live-Alarms Stored-Events ACM
Rx-Params CnC Stats Buffer MEO DPD
Use to monitor the status of the modem
and view the log of stored events for the
modem.
Test
TEST: Mode BERT Comp LED
Use to configure the modem into one of
several test modes or to configure/monitor
Store/Ld
Configuration #0 thru #9: Load Store
Use to store and load (recall) up to 10
different modem configurations.
Utility
Utilities: Set-RTC Display EventLog
CID AGC 1:1 1:N Circuit-ID Firmware
Use to perform miscellaneous functions,
such as setting the Real-Time Clock,
adjusting the display brightness, etc.
ODU
ODU: BUC PwrSupply+Ref (FUTURE)
LNB PwrSupply+Ref FSK-control (FUTURE)
When installed and available, use to
configure Outdoor Unit (BUC – Block Up
Converter or LNB – Low-Noise Block
Down Converter) operations.
FAST FAST: Options Demo-Mode CnC
Use to verify installed options and
configure different Fully Accessible
System Topology options, e.g., extended
data rates, interfaces, etc. Contact
Comtech EF Data Product Support for
To Next Page
