Comtech EF Data CDM-760 - CONFIG:) MEO (Medium Earth Orbit)

Front Panel Operation Revision 4
CDM-760 Advanced High-Speed Trunking Modem MN-CDM760
6–51
6.2.2.13 (CONFIG:) MEO (Medium Earth Orbit)
This menu is not available when in Normal (Geostationary) operation (Section
6.2.2.1.2 (CONFIG: NetSpec) Operating Mode).
AntId:0 AntStat:0 SatId:None Mute:0
Handover:00
This read-only screen displays information generated by the ACU (Antenna Controller Unit). Press
ENTER or CLEAR to return to the previous menu. Note the following:
Parameter Description
AntId This is the identification number of the antenna that is linked with the modem.
AntSat This is the status of the antenna that is linked with the modem.
SatId This is the identification number of the satellite that is linked with the modem.
Mute
This is the status of the BUC that is linked with the modem.
Handover This is the number of seconds remaining in the antenna handover window
