Front Panel Operation Revision 4
CDM-760 Advanced High-Speed Trunking Modem MN-CDM760
6–67
6.2.4.4 (TEST:) LED
Front Panel LED Test: Enabled
(Enable, Disable) ()
Use the arrow keys to select Enable and then press ENTER to execute a diagnostic test on
the front panel LED Indicators and the VFD.
The test run checks each LED Indicator, individually and as a group, while generating a series of
test patterns on the VFD. Normal operations resume upon completion of the test.
6.2.5 SELECT: Store/Ld (Store/Load)
Configuration #2: Load Store ()
No configuration exists.
You can store or load (recall) up to 10 different modem configurations – 0 through 9.
First, select your configuration: Use the arrow keys to navigate to Configuration #X (any
configuration location 0 through 9) entry. Then, use the arrow keys to select the desired
configuration number. Make note of the location status message on the bottom line:
• A location that is available to Store a configuration displays the message, “No
Configuration exists.”
• A location that displays the message, “A Configuration Exists.” is used to Load an
existing configuration.
Once you select a location, use the arrow keys to Load or Store the configuration. Press
ENTER.
When a modem configuration is stored to a location, the modem logs the date and time of this
configuration. This information – time in military/24-hour format / date in European convention
of DAY-MONTH-YEAR – is shown on the bottom line as the location number is edited.
6.2.5.1 Store/Load Override
Whether storing into a location and an existing configuration is already stored at this location, or
when loading a configuration into the working memory from a stored location, the message “A
configuration exists.” displays on the bottom line. The system requires you to confirm
the request, as it will permanently overwrite existing information:
Configuration #2. Override? No (Y,N) ()
A Configuration exists.
Use the arrow keys to select the Override choice – Y(es) or N(o) – and then press ENTER.
