Appendix C Revision 4
CDM-760 Advanced High-Speed Trunking Modem MN-CDM760
C–6
C.2.2.1 OC-3 Single/Multi Mode PIIC Module – Summary of Specifications
Item Description
Interfaces
•
OC-3 Single Mode (CEFD Kit KT-0000256)
•
OC-3 Multi Mode (CEFD Kit KT-0000257)
Data Rate 155.52 Mbps ±20 ppm
Framing and Signaling
SONET OC-3
SDH STM-1
Direction Full Duplex, allowing Tx/Rx only operation
Connectors Duplex LC
Fiber
•
Single Mode: 1300 nm, spectral width 7.7 nm rms
•
Multi Mode: 1300 nm, 62.5/125 µm, spectral width 63 nm rms
Typical Distance
•
Single Mode: Up to 15 Km
•
Multi Mode: Up to 500 m
Output Power
•
Single Mode: -12 dBm Typical
•
Multi Mode: -14 dBm Typical
Input Power
•
Single Mode: -31 dBm to -8 dBm
•
Multi Mode: -35 dBm to -30 dBm
Jitter G.825
Diagnostics
•
Baseband Loopback (at interface)
•
Interface Loopback (through interface module)
Rx Buffer 0.5 to 75 ms in 0.1 ms steps
