Appendix G Revision 4
CDM-760 Advanced High-Speed Trunking Modem MN-CDM760
G–5
Figure G-2. User Throughput vs. Time and Fades
Table G-3. Turning Margin into Additional Capacity
Parameter
SLA
Clear
2.2dB Fade
6.9dB Fade
Data Rate
25 Mbps
64 Mbps
51 Mbps
31 Mbps
ModCod
QPSK 3/5
16-APSK 5/6
16-APSK 2/3
QPSK 4/5
