Serial Interface Operation Revision 3
CDM-760 Advanced High-Speed Trunking Modem MN-CDM760
8–17
8.5.4 IP Packet Parameters
Parameter Type
Controller-to-Target
Instruction Code and
Qualifier
Arguments for
Command or
Query
Description of Arguments
(Note that all arguments are ASCII numeric codes from 48 to 57)
Target-to-Controller
(see Description of Arguments)
Command Query
Response to
Command
Response to
Query
Payload
Compression
EPC=
EPC?
1 byte, value of 0
thru 3
Command or Query.
Enable or Disable Payload Compression and Decompression in the form x, where:
0=Disable Decompression, Disable Compression
1=Disable Decompression, Enable Compression
2=Enable Decompression, Disable Compression
3=Enable Decompression, Enable Compression
EXAMPLE: <0/EPC=1 (selects decompression off and compression on)
EPC=
EPC?
EPC*
EPC#
EPC=x
Compression Stats
All
N/A
CSA?
21 bytes
Query only.
Returns all compression statistics, each separated by a colon, in the form x.xE+xx:x.xE+xx:xx:xx, where:
x.xE+xx=The total number of bytes into the compressor
x.xE+xx=The total number of bytes out of the compressor
xx=value from 00 to 99 (The percent savings or compression efficiency)
xx=value from 00 to 99 (The last 10 seconds percent savings or compression efficiency)
EXAMPLE: <0/CSA?
RESPONSE EXAMPLE 1: >0000/CSA=2.0E+03:1.0E+03:50:50
RESPONSE EXAMPLE 2: >0000/CSA=X.XE+XX:X.XE+XX:XX:XX (If the Compression Option Card is not present, then
all numeric fields display "X")
N/A
CSA=
x.xE+xx:x.xE+xx
:xx:xx
DeComp Stats All
N/A
DSA?
21 bytes
Query only.
Returns all decompression statistics, each separated by a colon, in the form x.xE+xx:x.xE+xx:xx:xx, where:
x.xE+xx=The total number of bytes into the decompressor
x.xE+xx=The total number of bytes out of the decompressor
xx=value from 00 to 99 The percent savings or decompression efficiency
xx=value from 00 to 99 The last 10 second percent savings or decompression efficiency
EXAMPLE: <0/ESA?
RESPONSE EXAMPLE 1: <0/DSA=2.0E+03:1.0E+03:50:50
RESPONSE EXAMPLE 2: <0/DSA=X.XE+XX:X.XE+XX:XX:XX (if the Decompression Option Card is not present, then
all numeric fields display "X")
N/A
DSA=x.xE+xx:x.
xE+xx:xx:xx
Clear Compression
Statistics
CCS=
N/A
None
Command only.
Clear Compression Statistics.
NOTE: THIS COMMAND TAKES NO ARGUMENTS.
EXAMPLE: <0/CCS=
CCS=
CCS?
CCS*
CCS#
N/A
Clear
Decompression
Statistics
CDS=
N/A
None
Command Only.
Clear Decompression Statistics.
NOTE: THIS COMMAND TAKES NO ARGUMENTS.
EXAMPLE: <0/CDS=
CDS=
CDS?
CDS*
CDS#
N/A
WAN Buffer Length
WBL=
WBL?
3 bytes
Command or Query.
Sets or returns WAN Buffer Length in ms, in 20 ms steps, in the form xxx where:
xxx=value from 20 to 400ms
EXAMPLE: <0/WBL=100
WBL=
WBL?
WBL*
WBL#
WBL=xxx
