Appendix H Revision 4
CDM-760 Advanced High-Speed Trunking Modem MN-CDM760
H–3
The CID message is composed of the following information:
• CDM-760 MAC Address • Device Location (Latitude and Longitude)
• Contact Telephone number • CID Custom Message
H.2 CDM-760 Carrier ID Operation
H.2.1 CDM-760 Operational Overview
Carrier ID operation requires that you first enable Carrier ID feature operation, and then create
a MetaCarrier Custom Message. All other parameters (center frequency, symbol rate, and the
CDM-760’s MAC address) are set automatically. The CDM-760 provides several means for
configuring Carrier ID operation:
• Local Control via the CDM-760 Front Panel keypad and VFD.
• Remote Control with a user-supplied PC via the:
o CDM-760 HTTP (Web Server) Interface using a compatible Web browser.
o Serial-based or Telnet-based Remote Control Interface using a terminal emulation
program or Windows Command-line.
o Ethernet-based Simple Network Management Protocol (SNMP) using a Network
Management System (NMS) and Management Information Base (MIB) File Browser.
USE OF THE SERIAL-BASED REMOTE CONTROL INTERFACE, THE TELNET-BASED
REMOTE CONTROL INTERFACE, AND THE ETHERNET-BASED SNMP INTERFACE ARE
RECOMMENDED ONLY FOR ADVANCED USERS. COMTECH EF DATA STRONGLY
ENCOURAGES USE OF THE CDM-760 FRONT PANEL OR HTTP (WEB SERVER)
INTERFACE FOR MONITOR AND CONTROL (M&C) OF THE CDM-760.
