Comtech EF Data CDM-760 - CONFIG: Tx) Mod; CONFIG:) Tx

Front Panel Operation Revision 4
CDM-760 Advanced High-Speed Trunking Modem MN-CDM760
6–8
When you select an Operating Mode other than what is active, the front panel displays this
message:
Configuring Operating Mode
Please Wait
6.2.2.2 (CONFIG:) Tx
Tx: Mod Data Freq Power ACM WANBuff
Data 155520.000kbps 060140.976ksps ()
On the top line, use the   arrow keys to select a parameter. Press ENTER. The read-only
bottom line shows the operating data rate (in kbps) and symbol rate (in ksps).
6.2.2.2.1 (CONFIG: Tx) Mod
ModCod=8PSK 8/9 Frame:Normal
Pilots:On ()
Use the   arrow keys to select a parameter. Press ENTER.
(CONFIG: Tx) Mod  ModCod, 0/0 (FEC)
Use the   arrow keys to toggle between selecting the ModCod or FEC.
For ModCod – Use the arrow keys to make your selection. Valid settings are QPSK, 8PSK,
16APSK, 32APSK, or ACM.
The 16APSK, 32APSK, and ACM (Adaptive Coding and Modulation) settings require that
the unit is already configured to permit these modulation types.
Select ACM for ACM Mode. In this mode, the modulator uses the ACM parameters (selected in the
CONFIG: Tx → ACM menu) and the remote Es/No modem reading to automatically set the
modulation type and FEC.
For FEC – Use the arrow keys to make your selection. Press ENTER. ModCods and coding are
valid for the listed network specifications as follows:
Network Spec QPSK 8PSK 16APSK 32APSK 64APSK
DVB-S2
1/2, 3/5, 3/4, 4/5,
5/6, 8/9, 9/10
3/5, 2/3, 3/4, 5/6,
8/9, 9/10
2/3, 3/4, 4/5, 5/6,
8/9, 9/10
3/4, 4/5, 5/6, 8/9,
9/10
---
DVB-S2-EB1
1/2, 8/15, 17/30,
3/5, 19/30, 2/3,
127/180, 3/4, 4/5,
5/6, 31/36, 8/9,
9/10
17/30, 3/5, 19/30,
2/3, 127/180, 3/4,
4/5, 5/6, 31/36, 8/9,
9/10
19/30, 2/3,
127/180, 3/4, 4/5,
5/6, 31/36, 8/9,
9/10
127/180, 3/4, 4/5,
5/6, 31/36, 8/9,
9/10
---
