Front Panel Operation Revision 4
CDM-760 Advanced High-Speed Trunking Modem MN-CDM760
6–68
6.2.6 SELECT: Utility
Utility: Set-RTC Display EventLog
CID AGC 1:1 1:N Circuit-ID Firmware
Use the arrow keys to select a parameter. Press ENTER
.
6.2.6.1 (Utility:) Set-RTC
Edit Real-Time Clock: dd/mm/yy
Time: 12:01:02 Date:26/10/14 ()
Time is in military/24-hour format. The date is in the European convention of DAY-MONTH-
YEAR.
Use the arrow keys to select a digit to edit, and then use the arrow keys to change that
digit. Press ENTER.
6.2.6.2 (Utility:) Display-Brightness
Edit Display Brightness:
100% ()
Use the arrow keys to select a suitable brightness level for the VFD (Vacuum Fluorescent
Display). The available levels are 25%, 50%, 75% or 100%. Press ENTER.
6.2.6.3 (Utility:) EventLog
EventLog Style: FillandStop
Use the arrow keys to select the Event Log Style. The available choices are Fill and Stop
and Fill and Roll Over. Press ENTER.
Note that:
• Fill and Stop allows the unit to record a maximum of 255 events. Once the unit records
Event 255, the unit ignores all subsequent events.
• Fill and Roll Over allows the unit to continue to record events in a continuous loop beyond
Event 255. Once the unit records Event 255, the unit rolls over the event log and continues
to log events beginning with Event 1 – overwriting the previous 255 events.
