Appendix F Revision 4
CDM-760 Advanced High-Speed Trunking Modem MN-CDM760
F–9
F.2 CDM-760 High-Speed Packet Processor Configuration and Operation
F.2.1 CDM-760 Operational Overview
After installation of the optional High-Speed Packet Processor, either in the factory or on site,
the CDM-760 provides several means for configuring Packet Processor operation:
• Local Control via the CDM-760 Front Panel keypad and VFD (used only for enabling or
disabling the Packet Processor).
• Remote Control with a user-supplied PC via the:
o CDM-760 HTTP (Web Server) Interface using a compatible Web browser.
o Ethernet-based Simple Network Management Protocol (SNMP) using a Network
Management System (NMS) and Management Information Base (MIB) File Browser.
USE OF THE ETHERNET-BASED SNMP INTERFACE IS RECOMMENDED ONLY FOR
ADVANCED USERS. ONCE YOU ENABLE PACKET PROCESSOR OPERATION FROM
USING THE CDM-760 FRONT PANEL, YOU SHOULD USE THE HTTP (WEB SERVER)
INTERFACE AS THE PRIMARY MEANS FOR MONITOR AND CONTROL (M&C) OF THE
CDM-760.
