Introduction Revision 4
CDM-760 Advanced High-Speed Trunking Modem MN-CDM760
1–3
1.2 Features
1.2.1 Physical Description
The CDM-760 Advanced High-Speed Trunking Modem is constructed as a 1RU-high rack-
mounting chassis. Handles at the front allow easy placement into and removal from a rack. The
unit can be free-standing if desired.
Physically, the modem is modular in design and is comprised of four major card assemblies, with
an internal expansion slot on the modem card that accepts other option cards such as Carrier-in-
Carrier (CnC) and K4 GZip lossless compression. Two Plug-In Interface Card (PIIC) slots are
provided on the modem rear panel to implement a variety of data interface options; this space
is also available to accommodate the optional High-Speed Packet Processor card.
1.2.1.1 Standard Assemblies
Assembly
Description
Where Installed
PL-0000596
Chassis (AC)
In chassis (top cover
access)
PL-0021161
Main Card Baseband Card (includes Ethernet Interfaces)
PL-0021262
Modulator Encoder Card / RF Front End
PL-0021263
Digital Demodulator / Decoder Card
PL-0000626
PIIC Motherboard Assembly
KT-0000150
AC Power Supply for modem (not BUC)
1.2.1.2 Optional Assemblies
Assembly
Description
Where Installed
PL-0000572
Carrier-in-Carrier Card
In chassis (top cover access), modem card plug-in
KT-0020958 High-Speed Packet Processor
In chassis (top cover access) – Kit replaces PIICs,
PIIC motherboard, plug-in card; provided faceplate
replaces PIIC Slots 1 and 2 chassis covers.
PL-0000635
K4 GZip Lossless Compression Card
In chassis (top cover access), modem card plug-in
IC-0000058
SFP Optical Gigabit Ethernet Data Interface
Rear Panel J7 | Optical port
PL-0000795
G.703 ‘BNC’ E3/T3/STS-1 PIIC Module
Real Panel PIIC Slots 1 and 2
KT-0000255
SFP STM-1 Copper ‘BNC’ PIIC Module
Real Panel PIIC Slots 1 and 2
KT-0000256
SFP OC-3 Single Mode PIIC Module
Real Panel PIIC Slots 1 and 2
KT-0000257
SFP OC-3 Multi Mode PIIC Module
Real Panel PIIC Slots 1 and 2
PL-0022015
DVB ASI (Asynchronous Serial Interface) PIIC
Module
Real Panel PIIC Slots 1 and 2
KT-0000168 Rear-Mounting Support Bracket (4”)
At rear sides of chassis, and rack rear mounting
rails
KT-0000195 Rear-Mounting Support Bracket (10”)
At rear sides of chassis, and rack rear mounting
rails
FP/SL0006
Bearingless Side Railings
On sides of chassis
