Rear Panel Connections Revision 4
CDM-760 Advanced High-Speed Trunking Modem MN-CDM760
3–13
3.3 Ground and Power Connections
3.3.1 Chassis Ground Interface
Figure 3-8. Chassis Ground Interface
Use the #10-32 stud, located adjacent to the power interface (Figure 3-8), for connecting a
common chassis ground among equipment.
CAUTION
CORRECT GROUNDING PROTECTION IS REQUIRED TO PREVENT PERSONAL INJURY
AND EQUIPMENT DAMAGE. YOU MUST MAKE SURE THE GROUND STUD ON THE REAR
PANEL OF THE UNIT IS ALWAYS CONNECTED TO PROTECTIVE EARTH.
The AC power interface provides the safety ground.
