C.2.4.1 DVB ASI (Asynchronous Serial Interface) PIIC Module – Summary
of Specifications
Item
Description
Data Rate
1 - 216 Mbps
Framing and Signaling
DVB-ASI, 188 and 204 Byte Framing
Jitter
EN 50083-9
Direction
Full duplex, allowing Tx/Rx only operation
Connectors
BNC-F, 75Ω
Output Level
800mVpp +/-10%
Input Level
200mVpp – 880mVpp
Diagnostics
•
Baseband Loopback (at interface)
•
Interface Loopback (through interface module)
Rx Buffer
0.5 to 75 ms in 0.1 ms steps
