Ethernet Interface Operation Revision 4

CDM-760 Advanced High-Speed Trunking Modem MN-CDM760

7–40

7.4.4.3.5.2 Configuration | WAN | Header Compression

Use this page to configure optional Header and Payload Compression when this FAST feature is

activated

and the optional High-Speed Packet Processor is installed and enabled.

Figure 7-20. Configuration | WAN | Header Compression Page

Compression Availability

Use the Header Compression drop-down list to select Enable or Disable.

Click [Submit] to save.

Refresh Rates

Enter a refresh rate time, from 1 to 600 seconds, for each item. Note the following:

Term

Description

RTP

Real Time Protocol

UDP

User Datagram Protocol

Click [Submit] to save.
