8.5 Remote Commands and Queries
8.5.1 Table Indexes
NOTES:
1) Index Columns – Where Column ‘C’=Command, and Column ‘Q’=Query, columns marked ‘X’ designate the instruction code as Command
only, Query only, or Command or Query.
2) In the Sect. 8.5.2 thru 8.5.X tables, the following codes are used in the ‘Response to Command’ column (per Sect. 8.4.2.5):
= Message ok # Message ok, but unit is not in Remote mode.
? Received ok, but invalid arguments were found. ~ Time out of a pass-through message to a local ODU
^ Message ok, but unit is in Ethernet mode.
Sect. 8.5.2 Tx Parameters
CODE C Q PAGE CODE C Q PAGE CODE C Q PAGE CODE C Q PAGE CODE C Q PAGE
TAR
X X
8-13 TFQ
X X
8-11 TMC
X X
8-11 TSI
X X
8-12
TDR
X X
8-12 TGS
X X
8-13 TPI
X X
8-13 TSR
X X
8-12
TFM
X X
8-11 TPL
X X
8-13 TXO
X X
8-13
Sect. 8.5.3 Rx Parameters
CODE C Q PAGE
CODE C Q PAGE CODE C Q PAGE CODE C Q PAGE
CODE C Q PAGE
EBA
X X
8-16 RAR
X
8-16 RFQ
X X
8-14 RPI
X
8-16
RDR
X
8-15
RGS
X X
8-16
RSI
X
8-15
RFM
X
8-14
RMC
X
8-14
RSR
X X
8-15
Sect. 8.5.4 IP Packet Parameters
CODE
C
Q
PAGE
CODE
C
Q
PAGE
CODE
C
Q
PAGE
CODE
C
Q
PAGE
CODE
C
Q
PAGE
CCS
X
8-17
CSA
X
8-17
EPC
X X
8-17
WBL
X X
8-17
CDS
X
8-17 DSA
X
8-17 ST1
X
8-18
