Front Panel Operation Revision 4
CDM-760 Advanced High-Speed Trunking Modem MN-CDM760
6–41
6.2.2.4.4.3.5 (CONFIG: INTF) (PIICX=ASI)  Center (Rx Buffer Re-Center)
PIICX: TxMode RxMode ClkSource Mask
BufSize:32.0mS Center:No Fill:99% ()
The Fill Status is a read-only status of buffer depth, reported as a percentage:
• If the Fill Status is decreasing (approaching 0%), then the Rx traffic is arriving too slowly for the
Rx Clock setting, causing a data underflow.
• If the Fill Status is increasing (approaching 100%), then the Rx traffic is arriving too quickly for
the Rx Clock setting, causing a data overflow.
If this value indicates a data underflow or overflow, then use the  arrow keys to select Yes
to re-center the Rx Buffer depth to 50%.
6.2.2.4.5 (CONFIG: INTF) PacketProcessor
Packet Processor: Enabled
()
Use the  arrow keys to select the installed optional High-Speed Packet Processor’s operation
as Enabled or Disabled. Press ENTER.
6.2.2.5 (CONFIG:) CnC (Carrier-in-Carrier)
Appendix J. DOUBLETALK CARRIER-IN-CARRIER (CNC) OPTION
CnC: Mode:Off Min Search Delay:230 ms
Max Search Delay:290 ms ()
Use the   arrow keys to select a parameter. Press ENTER.
6.2.2.5.1 (CONFIG: CnC) Mode
CnC operation requires installation of the DoubleTalk Carrier-in-Carrier module. With
no module installed, CnC Mode is forced Off and this submenu is inoperable. You must
also purchase one of several available FAST options to provide capability to a
maximum of 155 Mbps.
Use the arrow keys to select CnC operation as Off or On. Press ENTER.
