Comtech EF Data CDM-760 - Page 281

Serial Interface Operation Revision 3
CDM-760 Advanced High-Speed Trunking Modem MN-CDM760
8–38
Parameter Type
Controller-to-Target
Instruction Code and
Qualifier
Arguments for
Command or
Query
Description of Arguments
(Note that all arguments are ASCII numeric codes from 48 to 57)
Target-to-Controller
(see Description of Arguments)
Command Query
Response to
Command
Response to
Query
Equipment ID
N/A
EID?
29 bytes
Query only
Returns the equipment ID and installed options in the form AAAABCDEFGHIJKLMNOPQUSTUVWXYZ , where:
AAAA=0760 , the modem model number
Installed hardware:
B=Modulator 0=not present, 1=present
C=Demodulator 0=not present, 1=present
D=Gzip 0=not present, 1=present
E=Packet Processor 0=not present, 1=present
F=CnC/DPD, 0=not present, 1=present
G=PIIC1
1
H=PIIC2
1
I=Optical Present 0=not present, 1=present
J=Reserved
1
PIIC cards will be reported as:
0=not present
1= ASI
2=G.703
3=OC3
4=reserved
Software FAST options:
K=CnC Data Rate
0=None/Off
1=5 Mbps
2=10 Mbps
3=15 Mbps
4=20 Mbps
5=25 Mbps
6=30 Mbps
7=40 Mbps
8=52 Mbps
9=75 Mbps
A=100 Mbps
B=125 Mbps
C=160 Mbps
D=225 Mbps
E=275 Mbps
L=Fractional CnC
0=Not Installed
1=Installed
EID#
EID=AAAABCD
EFGHIJKLMNO
PQUSTUVWXY
Z
