Control Techniques Commander SK User Manual

Introduction Parameter x.00
Parameter
description format
Keypad and
display
CT Modbus
RTU
User
programming
CT Soft Menu 0
Advanced parameter
descriptions
Menu 11
Commander SK Advanced User Guide 123
Issue Number: 2 www.controltechniques.com
This parameter has two possible values and indicates the voltage rating of the drive.
0: 200 200V product
1: 400 400V product
See Pr 11.29 on page 122.
This parameter indicates the version of DSP software fitted.
This parameter sets the timeout in seconds for the drive display to revert to status mode from edit mode following no presses of the keypad. Although
this parameter can be set to less than 2s, the minimum timeout is 2s.
The SmartStick should only be installed and removed when power to the drive has been turned off.
This parameter selects the mode of operation for the cloning module. 4 options are available
When data is programmed to the SmartStick it takes the information directly from the drives EEPROM memory thus taking a copy of the stored
configuration of the drive rather than the current configuration in drive RAM. The drive takes action on the command when the user exits the
parameter edit mode. Also, to be backwards compatible with Commander SE and to allow cloning over the serial interface, the drive will action the
value programmed on a drive reset.
11.33 Voltage rating
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
11111
Range 0 (200), 1 (400)
Update rate N/A
11.34 Software sub-version
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111 1
Range 0 to 99
Update rate N/A
11.35 DSP software version
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
11 1 1 1
Range 0.0 to 9.9
Update rate N/A
11.36 to 11.40 Unused parameters
11.41 Status mode timeout
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Range 0 to 250 s
Default 240
Update rate Background
11.42 Parameter cloning
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
1111
Range 0 (no), 1 (rEAd), 2 (Prog), 3 (boot)
Default 0 (no)
Update rate Actioned on exit of edit mode and on drive reset
Value Display Function
0 no No action
1 rEAd Read parameters from the SmartStick
2 Prog Write parameters to the SmartStick
3 boot Set the SmartStick as master, so it becomes read only.
NOTE
