If Pr 6.17 = 1, the energy meter (Pr 6.24 and Pr 6.25) is reset and held at zero.
The run time log increments when the drive inverter is active to indicate the amount of time that the drive has been running since leaving the
manufacturing plant. In the event of drives never being switched off, the value of this parameter will be updated in EEprom after every 24hours of
running.
The energy meter indicates the energy supplied from the drive in kWh. Pr 6.24 and Pr 6.25 give an accumulated value of power used.
The energy meter is reset and held at zero when Pr 6.17 = 1.
This parameter gives an instantaneous read out of the cost/hour of running the drive. This requires Pr 6.16 to be set up correctly.
6.17 Reset energy meter
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Range 0 or 1
Default 0
Update rate Background
6.18 to 6.21 Unused parameters
6.22 Run time log: years.days
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
3111 11
Range 0.000 to 9.365 years.days
Update rate Background
6.23 Run time log: hours.minutes
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
2111 11
Range 0.00 to 23.59 hours.minutes
Update rate Background
6.24 Energy meter: MWh
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
1111 1
Range 0.0 to 999.9 MWh
Update rate Background
6.25 Energy meter: kWh
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
2111 1
Range 0.00 to 99.99 kWh
Update rate Background
6.26 Running cost
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
1 111
Range
±3200 currency/hour
Update rate Background
6.27 to 6.28 Unused parameters
