Control Techniques Commander SK User Manual

Introduction Parameter x.00
Parameter
description format
Keypad and
display
CT Modbus
RTU
User
programming
CT Soft Menu 0
Advanced parameter
descriptions
Menu 6
Commander SK Advanced User Guide 73
Issue Number: 2 www.controltechniques.com
3. OR Run forward and Run reverse are both active and have been for 60ms.
The drive can then be restarted by activating the necessary bits to give a normal start. This means that the drive cannot restart automatically after a
trip, for example, by pressing the stop key.
Sequencer latching enabled (Pr 6.40 = 1)
If the stop key is pressed when the stop key is enabled (Pr 6.12 = 1) or when the drive is tripped the sequencer run is removed, and so the drive stops
or remains stopped respectively. The sequencer run can only then be reapplied after at least on of the following conditions occurs.
1. Run forward, Run reverse and Run sequencing bits all zero after the latches
2. OR Not stop sequencing bit is zero
3. OR the drive is disabled via Pr 6.15 or Pr 6.29
4. OR Run forward and Run reverse are both active and have been for 60ms.
The drive can then be restarted by activating the necessary bits to give a normal start. This means that the drive cannot restart automatically after a
trip, for example, by pressing the stop key. Note that Run forward and Run reverse together will reset the stop key condition, but the latches
associated with Run forward and Run reverse must then be reset before the drive can be restarted.
On the LCD keypad:
This parameter enables the Fwd/Rev key to operate in keypad mode.
On the LED keypad:
0: No Function
1: Forward/Reverse toggle
2: Run Reverse
3:Jog
4: Hand off auto
5:Function
0: Auto reset on enable enabled
1: Auto reset on enable disabled
If this parameter is set to 1, the automatic reset on the toggle of the enable terminal of the drive is disabled.
0: Drive disabled
1: Drive enabled
Setting this parameter to 0 will disable the drive. It must be at 1 for the drive to run.
When this parameter is set up correctly for the local currency, Pr 6.26 will give an instantaneous read out of running cost.
6.13 Function key mode
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
11
Range 0 to 5
Default 0
Update rate Background read
6.14 Disable auto-reset on enable
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Range 0 or 1
Default 0
Update rate 2 ms
6.15 Drive enable
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
1 111
Range 0 or 1
Default 1
Update rate 2 ms
6.16 Electricity cost per kWh
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
1 111
Range 0.0 to 600.0 Currency/kWh
Default 0.0
Update rate Background
