Introduction Parameter x.00
Parameter
description format
Keypad and
display
CT Modbus
RTU
User
programming
CT Soft Menu 0
Advanced parameter
descriptions
Menu 1
Commander SK Advanced User Guide 27
Issue Number: 2 www.controltechniques.com
This parameter is used to select a preset speed reference as follows:
0 Preset selection by terminal input
1 Preset 1 selected if Pr 1.49 = 3, AN1 selected if Pr 1.49 = 1, AN2 selected if Pr 1.49 = 2
2 Preset 2 selected
3 Preset 3 selected
4 Preset 4 selected
5 Preset 5 selected
6 Preset 6 selected
7 Preset 7 selected
8 Preset 8 selected
When this parameter is set to 0 the preset selected depends on the state of bit parameters Pr 1.45, Pr 1.46 and Pr 1.47. These bits are for control by
digital inputs such that presets can be selected by external control. The preset selected depends on the binary code generated by these bits as
follows:
Pr 1.50 indicates the preset selected at all times.
If the reference selected by Pr 1.14 (or Pr 21.03) is 1 or 2 (current or voltage) a preset will be selected instead of the current or voltage selection if the
preset selected is any other than 1. This give the user the flexibility to be able to select between voltage and 3 presets, or current and three presets,
with only two digital inputs.
This parameter is the reference used when keypad reference is selected.
The range depends on the setting of Pr 1.10:
Pr 1.10 Range
0:Pr 1.07 to 1500 Hz or Pr 21.02 to 1500 Hz
1:±1500 Hz
1.15 Preset selector
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Range 0 to 8
Default 0
Update rate 5ms
Pr 1.47 Pr 1.46 Pr 1.45 Preset selected Pr 1.50
0001 (if Pr 1.49 = 3)
001 2
010 3
011 4
100 5
101 6
110 7
111 8
1.16 Unused parameter
1.17 Keypad reference
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
11 1 1 1
Range ±1500.0Hz
Default 0.0
Update rate Background
1.18 Precision reference coarse
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
11 11
Range ±1500.0Hz
Default 0.0
Update rate 5ms
