9.6 Menu 5: Machine control
Table 9-7 Menu 5 parameters: single line descriptions
Parameter Range Default Setting Update Rate
5.01 Output frequency ± 1500 Hz
21 ms
5.02 Output voltage
0 to AC_
VOLTAGE_MAX V
B
5.03 Output power ±POWER_MAX kW
B
5.04 Motor rpm ± 9999 rpm
B
5.05 DC bus voltage
0 to +DC_
VOLTAGE_MAX V
B
5.06 Motor rated frequency {39} 0.0 to 1500.0 Hz 50.0(EUR), 60.0(USA) B
5.07 Motor rated current {06}
0 to RATED_
CURRENT_MAX A
Drive rated current
{Pr 11.32}
B
5.08 Motor rated full load rpm {07} 0 to 9999 rpm
1500(EUR)
1800(USA)
B
5.09 Motor rated voltage {08}
0 to AC_
VOLTAGE_SET_
MAX V
200 V drive: 230
400 V drive: 400(EUR)
460(USA)
128 ms
5.10 Motor rated power factor {09} 0.00 to 1.00 0.85 B
5.11 Number of poles {40} 0 to 4 0 (Auto) B
5.12 Auto-tune {38} 0 to 2 0 B
5.13 Dynamic V to F select {32}0 or 1 0 B
5.14 Voltage mode select {41} 0 to 5 4 B
5.15 Low frequency voltage boost {42}
0.0 to 50.0% of motor
rated voltage
3.0 B
5.16 Not used
5.17 Stator resistance 0.000 to 65.000 Ω 0.000 B
5.18 Maximum switching frequency {37} 0 to 3 0 B
5.19 High stability space vector modulation 0 or 1 0 B
5.20 Over modulation enable 0 or 1 0 B
5.21 Not used
5.22 Not used
5.23 Voltage offset 0.0 to 25.0 V 0.0 B
5.24
Transient inductance (σL
s
)
0.000 to 320.00 mH 0.000 B
5.25 Not used
5.26 Not used
5.27 Enable slip compensation 0 or 1 1 B
5.28 Not used
5.29 Not used
5.30 Not used
5.31 Not used
5.32 Not used
5.33 Not used
5.34 Speed display units {23} 0 to 2 0 B
5.35 Disable auto-switching frequency change 0 or 1 0 B
5.36 Not used
5.37 Actual switching frequency 0 to 3 BW
5.38 Not used
5.39 Not used
5.40 Not used
5.41 Not used
5.42 Not used
5.43 Not used
5.44 Not used
5.45 Not used
5.46 Not used
5.47 Not used
5.48 Not used
5.49 Not used
5.50 Security unlock 0 to 999 BR
