Control Techniques Commander SK User Manual

Menu 6 Introduction Parameter x.00
Parameter
description format
Keypad and
display
CT Modbus
RTU
User
programming
CT Soft Menu 0
Advanced parameter
descriptions
66 Commander SK Advanced User Guide
www.controltechniques.com Issue Number: 2
9.7 Menu 6: Drive sequencer and clock
Table 9-8 Menu 6 parameters: single line descriptions
Parameter Range Default Setting Update Rate
6.01 Stop mode {31} 0 to 4 1 2 ms
6.02 Not used
6.03 Mains loss mode 0 to 2 0 2 ms
6.04 Start/stop logic select {11} 0 to 6
0 (EUR)
4 (USA)
Drive reset
6.05 Not used
6.06 Injection braking level 0.0 to 150.0% 100.0 B
6.07 Injection braking time 0.0 to 25.0 s 1.0 2 ms
6.08 Not used
6.09 Catch a spinning motor {33} 0 to 3 0 B
6.10 Low DC bus operation 0 or 1 0 B
6.11 Remote LED keypad function key status 0 or 1 0 B
6.12 Permanently enable stop key 0 or 1 0 B
6.13 Function key mode 0 to 5 0 BR
6.14 Disable auto reset on enable 0 or 1 0 2 ms
6.15 Drive enable 0 or 1 1 2 ms
6.16 Electricity cost per kWh 0.0 to 600.0 currency/kWh 0.0 B
6.17 Reset energy meter 0 or 1 0 B
6.18 Not used
6.19 Not used
6.20 Not used
6.21 Not used
6.22 Run time log: years.days 0.000 to 9.365 years.days B
6.23 Run time log: hours.minutes 0.00 to 23.59 hours.minutes
B
6.24 Energy meter: MWh 0.0 to 999.9 MWh
B
6.25 Energy meter: kWh 0.00 to 99.99 kWh
B
6.26 Running cost ±32000 currency/hour
B
6.27 Not used
6.28 Not used
6.29 Permanent hardware enable 0 or 1 1 2 ms
6.30 Sequencing bit: Run forward 0 or 1 0 2 ms
6.31 Sequencing bit: Jog forward 0 or 1 0 2 ms
6.32 Sequencing bit: Run reverse 0 or 1 0 2 ms
6.33 Sequencing bit: Fwd/Rev 0 or 1 0 2 ms
6.34 Sequencing bit: Run 0 or 1 0 2 ms
6.35 Forward limit switch 0 or 1 0 2 ms
6.36 Reverse limit switch 0 or 1 0 2 ms
6.37 Sequencing bit: Jog reverse 0 or 1 0 2 ms
6.38 Not used
6.39 Sequencing bit: not stop 0 or 1 0 2 ms
6.40 Enable sequencer latching 0 or 1 0 2 ms
6.41 Not used
6.42 Control word 0 to 32767 0 2 ms
6.43 Control word enable 0 or 1 0 2 ms
6.44 Not used
6.45 Force cooling fan to run at full speed 0 or 1 0 B
